AC-DC Converters
| Series | Rated power (W) | Input voltage (V) | Output current (A) | Output voltage (V) | Isolation voltage (V) | Certificate | Dimension | Spec |
|---|---|---|---|---|---|---|---|---|
|
PMS5
|
5W | 85-305VAC | 0.23-1.25A | 3.3-24VDC | 3000VAC | CE | 46.08x25.78x21.7mm | - |
|
PMS10
|
10W | 85-305VAC | 0.42-2.5A | 3.3-24VDC | 3000VAC | CE | 46.08x25.78x21.7mm | - |
|
PMS15
|
15W | 85-305VAC | 0.63-3.5A | 3.3-24VDC | 3000VAC | CE | 52.6x27.48x24.3mm | - |
|
PMS20
|
20W | 85-305VAC | 0.9-4.5A | 3.3-24VDC | 3000VAC | CE | 52.6x27.48x24.3mm | - |
|
PMS30
|
30W | 85-305VAC | 0.625-6A | 5-48VDC | 3000VAC | CE | 69.5x39x24mm | - |
|
PMS30T
|
30W | 85-305VAC | 0.625-6A | 5-48VDC | 3000VAC | CE | 91x39.5x28.mm | - |
|
PMS45
|
45W | 85-305VAC | 0.94-8A | 5-48VDC | 3000VAC | CE | 87x52x3mm | - |
|
PMS45T
|
45W | 85-305VAC | 0.94-8A | 5-48VDC | 3000VAC | CE | 109.3x52.7x33.9mm | - |
|
PMS60
|
60W | 85-305VAC | 1.25-10A | 5-48VDC | 3000VAC | CE | 87x52x3mm | - |
|
PMS60T
|
60W | 85-305VAC | 1.25-10A | 5-48VDC | 3000VAC | CE | 109.3x52.7x33.9mm | - |
|
PMS90
|
90W | 85-305VAC | 1.88-6.7A | 12-48VDC | 3000VAC | CE | 87x52x3mm | - |
|
PMS90T
|
90W | 85-305VAC | 1.88-6.7A | 12-48VDC | 3000VAC | CE | 109.3x52.7x33.9mm | - |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
